400G OSFP-RHS AOC

The GIGALIGHT 400G OSFP AOC active optical cable is designed for 400G Ethernet links in data centers. It uses 100G PAM4 and VCSEL technology to interconnect up to 425Gbps of data within 30m (OM3) or 50m (OM4) with the system FEC turned on.

Description

  • Active fiber optic cable assembly with one 400G OSFP-RHS SR4 optical transceiver module on each end
  • 4-channel 850nm VCSEL and PIN on each end
  • Transmission rates up to 112Gbps per channel (112G PAM4)
  • Compliant with OSFP MSA, CMIS4.0 and IEEE 802.3db transport protocols
  • Transmission over distances up to 30m (OM3) or 50m (OM4) using 4 parallel pairs of multimode fiber optics
  • Commercial grade operating temperature range
  • Power consumption less than 8W
  • Supply voltage 3.3V
  • RoHS compliant (lead-free)

Additional information

Product Type

Active Optical Cables

Application

Data Center

Data Rate

Protocol

,

Form Factor

Reach

Media Type

Wavelength

Data Sheet

GOP-MDO401-XXXC

Ordering Information

产品名称速率距离功耗规格书
400G OSFP-RHS AOC425Gbps30m(OM3)
50m(OM4)
8WGOP-MDO401-XXXC
